1,Product Introduction
ZNSJ high strength construction templates is formed at high temperatures and pressures using the structure of “bamboo mat+thin bamboo curtain+special
phenolic glue”. The special phenolic glue is research-developed by the specialist in Central South University of Forestry and Technology, which is
higher 2-3 baume degree than counterparts in glue adhesiveness and concentration. Therefore our high strengthbamboo plywood have the characteristics
of higher bonding strength, higher waterproof, no tacking, and its turnover use time will be more than 20 times.
2,Product Advantages
1)Bamboo plywood is with glossy and smooth surface;
2)Multi- using times and long lifespan :
3)Good water resistant performance;
4)Low thermal conductivity;d can be sawed and nailed, which can effectively reduce the quantity of supporting formworks.
Items |
Parameters |
Product Name |
Bamboo plywood, packing plywood, commercial plywood, Film faced Plywood , film faced bamboo plywood, bamboo formwork, bamboo board, bamboo pannel, bamboo plywood sheet, bamboo plywood for construction |
Specifications |
1220*2440*(8-20)mm 1830*915*(9-10)mm |
Glue |
Phenolic glue |
Materials |
Bamboo |
Moisture Content |
≤10% |
Density |
≥0.90g/m3⊥ |
Modulus Of Elasticity |
//≥7×103N/mm2 ⊥5×103N/mm2 |
Modulus Of Rupture |
//≥90N/mm2 //≥60N/mm2 |
Impact Strength |
≥60Kg/m2 |
Bonding Strength |
≥0.80N/mm2 |
Abrasion Value |
<0.80g/100r |
Using times |
10-15times |
Preservation Stregth |
//≥60N/mm2 ⊥≥40N/mm2 |
Specifications |
Thickness(mm) |
Weight(kg/piece) |
1 20ft can load(pieces) |
1.22*2.44 |
8 |
20.24 |
990 |
9 |
22.77 |
880 |
|
10 |
25.3 |
792 |
|
11 |
27.83 |
720 |
|
12 |
30.36 |
660 |
|
13 |
32.89 |
609 |
|
14 |
35.42 |
566 |
|
15 |
37.95 |
528 |
|
16 |
40.48 |
495 |
|
17 |
43.01 |
466 |
|
18 |
45.54 |
440 |
